UM4BG1
Medium Duty
- Duty Cycle; Operation up to 60% of the time at rated power and speed.
- Typical operation hours; Continuous usage is allowed up to 6 hours and annual usage up to 3000 hours.
Light Duty
- Duty Cycle; Operation up to 40% of the time at rated power and speed.
- Typical operation hours; Continuous usage is allowed up to 2 hours and annual usage up to 2000 hours.
- Rated output kW(PS)/min-1 – Medium duty: 81 (110) / 2900
- DisplacementLit. (cid) 4.32 (264)
- Bore x Strokemm (in) 105 × 125 (4.13 × 4.92)
- Configuration 4-cylinder, vertical in-line, 4-cycle deisel engine
- Aspiration Natural aspiration
- Marine gear Model MGN35A
- Marine gear Reduction ratio 2.56, 3.05, 3.45
- Leaflet PDF
- Engine Model: UM4BG1TCX
- Rated output kW(PS)/min-1 – Medium duty: 134 (182) / 2700
- Rated output kW(PS)/min-1 – Light duty: 147 (200) / 2800
- DisplacementLit. (cid) 4.32 (264)
- Bore x Strokemm (in) 105 × 125 (4.13 × 4.92)
- Configuration 4-cylinder, vertical in-line, 4-cycle deisel engine
- Aspiration Turbo chargered / Intercooler
- Exhaust gas status IMO Tier II
- Marine gear Model MGN35A
- Marine gear Reduction ratio 2.56, 3.05, 3.45
- Leaflet PDF
